LiFePO4
Item Number: SL-24V-150Ah
| Capacity | 25.6V30Ah 768W |
|---|---|
| Cycles | 3000 |
| Shell material | ABS |
Contact Now
- Specifications
- Function
- Application
- Features
- Downloads
| Dimensions (mm) | 520*269*220 |
| Terminal | M8 |
| Accessories | Screws, insulating caps, handles, instructions |
| Net weight | 28KG |
| Rated power | 1920W |
| Working voltage | 25.6V |
| Maximum charging voltage (V) | 29.2 |
| Discharge cut-off voltage (V) | 20.0 |
| Working current | 0-100A |
| Charging time | 2.0H 0.5C current |
| Use time | 1.5H 100A current |
-
lithium battery protection board
The lithium battery protection board has five functions of overcharge, overdischarge, overcurrent, overtemperature, short circuit and protection.
-
Bluetooth model (optional)
Mobile phone APP function: 1. View battery working status; 2. View BMS parameters; 3. Modify BMS parameters;
-
Charging and heating (optional)
1. Charging and heating function: support charging below 0°C; 2. Charging current limiting function; when the batteries are connected in parallel, the charging current limiting can inhibit circulating current and mutual charging. Extend battery life.
-
With voltage display (optional)
Real-time display of battery voltage; display of battery reference power. Note: The voltmeter is a simple model. The power displayed is for reference only.
-
With fuel gauge display (optional)
Real-time display of battery power, voltage, temperature, and current information. Tabbed display of single-cell battery voltage.
-
Standard model
Support 4 series or 4 parallel use, standard charging voltage 29.2V, charging current 0.2C, continuous discharge current 1C, instantaneous discharge current 60A (3s), discharge cut-off voltage 20V, over-temperature protection 65℃.
-
Home energy storage
-
RV
-
Base station backup power
-
ups
-
Electric boat
-
Motorcycle
-
Golf cart
-
Emergency Rescue
-
Fishing
-
Intelligent control system
The 5th generation fully intelligent battery control system is independently developed, with six functions of overcharge, overdischarge, overcurrent, reverse connection, overtemperature and short circuit protection.
-
Deep charge and discharge
100% DOD.
-
Cycle life
Lithium battery has a higher energy density and a longer cycle life, with an average of 300-500 times for lead-acid batteries and more than 2000 times for lithium batteries.
-
Mass and volume
In the case of the same capacity, lead-acid batteries are heavier and larger than lithium batteries.
-
Battery capacity
Compared with lead-acid batteries, the average voltage of lithium batteries is higher, and its energy density is high. In other words, the capacity of lithium batteries is larger for batteries of the same size.
-
Warranty period
The warranty period of lead-acid batteries is generally 1 year, while the warranty period of lithium batteries is longer and can be guaranteed for 2 years.
-
Lithium battery advantages
Compared with lead-acid batteries, lithium batteries are smaller, lighter, more portable, and have a relatively longer lifespan. In addition, lithium batteries have greater energy, can provide greater current, and are more adaptable to high and low temperatures, less affected by temperature, and more environmentally friendly.
-
